Real-Time Hybrid Testing



CIRST
Cyber-physical Instrument for Real-time hybrid Structural Testing (CIRST)
Real-time hybrid testing combines simulation and physical testing to help in assessing structural integrity in large scale civil infrastructure. The RTHS test frame in the IISL allows for configurable testing of the real components in the system, while actuators impose forces determined by the numerical components.



Shake Tables



Shake Table Six Degree of Freedom Shake Table
Run by six hydraulic actuators, this small-scale shake table allows motion ranging up to six degrees of freedom, including translation and rotation about the three orthogonal axes. This shake table is typically used to test small scale multi-degree of freedom building systems. The shake table operation is controlled through dSpace.



Small-scale Earthquake Simulator Single Degree of Freedom WinCon Shake Table
This shake table was constructed by Quanser Consulting and serves as the standard shake table of the UCIST consortium. The shake table operation is controlled through WinCon and MatLab.



Small-scale Earthquake Simulator Single Degree of Freedom Tele-operation Shake Table
This shake table operates in both local and remote applications, enabling joint research projects with various laboratories. The shake table operation is controlled through LabVIEW.



Small-scale Earthquake Simulator Single Degree of Freedom XPc Shake Table




Structural Models



Cable-stayed Experimental Model Cable-stayed Experimental Model
Used to verify various structural health monitoring techniques.





Cable-stayed Experimental Model Small-Scale Steel Bridge with Adjustable Boundary Conditions
Used to study the response modification of bridges, particularly under the influence of pedestrian traffic.





Dynamic Motion and Measurement System Full-Scale Highway Sign Truss
Used to study the structural health monitoring applications.



Measurement Systems



Dynamic Motion and Measurement System Krypton Dynamic Motion and Measurement System
Allows for the collection of real-time 3-D position data. Also able to calculate horizontal/vertical strains, and animations of the LEDs movement.
Manufacturer: Metris, Inc.
