PF22


BRAKECustom Machined Rotors, Wilwood GP200 Front Caliper, AP Racing Rear Caliper
COOLINGDual Aluminum Radiator with mounted fan, Electric Water Pum
DRIVEChain drive, Drexler LSD
ELECTRONICSMotec M130 ECU, PDM15, and C125 Color Dash Display
ENGINENaturally-aspirated Yamaha WR450 (1-Cylinder, 449cc)
FR/RR Track47 in/46 in
FRAMESpace frame 4130-N Chromoly Steel
FUEL SYSTEMPort Injection with Injector Dynamics Injector
FUEL TYPE93 Octane Gasoline
MATERIALSteel, Aluminum, Carbon Fiber
MPD52hp @8,000rpm
MPT33.7 ft-lbf @4,000rpm
OLWH115″ x 55″ x 46″
SUSPENSIONSLA Double Wishbone Pushrod Actuated with Ohlins Dampers
TIREHoosier 18.0×6-10 LC0 on 7in Wheel
UNIQUE3D Printed Intake, Launch Control
WEIGHT388 lb
WHEELBASE61 in

Overall 6th
Design 3rd
Business 2nd
Skidpad 3rd
Autocross 11th
Endurance9th

Overall 2nd
Design 2nd
Skidpad 1st
Acceleration11th
Endurance2nd
Autocross 3rd

PF20


BRAKECustom Machined Rotors, Wilwood GP200 Front Caliper, AP Racing Rear Caliper
COOLINGDual Aluminum Radiator with mounted fan, Electric Water Pump
DRIVEChain drive, Drexler LSD
ELECTRONICSMotec M130 ECU, PDM15, and C125 Color Dash Display
ENGINENaturally-aspirated Yamaha YZF-R6 (4 cylinder, 599cc)​
FR/RR Track47 in/46 in
FRAMESpace frame 4130-N Chromoly Steel
FUEL SYSTEMPort Injection with Deatschwerks Injectors
FUEL TYPE93 Octane gasoline
MATERIALSteel, Aluminum, Carbon Fiber
MPD42.4 ft-lbf @ 10000rpm
MPT82.8 hp @ 11000rpm
OLWH115″ x 55″ x 46″
SUSPENSIONSLA Double Wishbone Pushrod Actuated with Ohlins Dampers
TIREHoosier 18.0×6-10 LC0 on 7in Wheel
UNIQUE3D Printed Intake, Launch Control
WEIGHT440 lb
WHEELBASE61 in

Overall 6th
Skidpad 15th
Acceleration12th
Autocross 5th
Endurance4th

Overall 9th
Skidpad 3rd
Acceleration8th
Autocross 9th

Overall 2nd
Design 2nd
Cost 21st
Presentation2nd
