Due 3/27

# Tree sort

## Goals

The goals of this assignment are as follows:
1. Practice writing code using binary search trees (dynamic structures).
2. Practice writing code using recursion.
3. Learn to use function addresses (function pointers).
4. Learn to use the `qsort(…)` function.
5. Gain some perspective on different sorting algorithms.

## Overview

This homework is about sorting. You will implement the tree sort algorithm to help you learn about binary search trees (BSTs) and sorting algorithms. For the more practical approach, you will also write a wrapper function for the standard `qsort(…)` function, an implementation of the quicksort algorithm.

Note: `quick_sort_array(…)` is completely separate from `tree_sort_array(…)`. They are alternative ways of sorting an array. They should have the same result. They do not call each other. We are including `quick_sort_array(…)` mainly so you can get some experience with function addresses, and so you don't go away thinking that you need to actually implement sorting algorithms in the real world.

There are no starter files.

## Outline of a solution

👌 Okay to copy/adapt anything you see in these two screenshot images. (You may not copy code from lecture or anywhere else.)

## Demonstration

Reminder: Do not copy this code or anything else into your code (unless marked as "Okay to copy/adapt" by one of the instructors). However, you may run this in your account by running `264get HW10`.
```#include <stdio.h>
#include <stdlib.h>
#include <stdbool.h>
#include <assert.h>
#include "sorts.h"

void _print_array(int* array, size_t size, const char* title) {
printf("%s\n", title);
for(int i = 0; i < size; i++) {
printf("%d ", array[i]);
}
printf("\n\n");
}

int main(int argc, char* argv[]) {

// Demonstrate create_bst(…)
BST bst = create_bst((int[7]) { 4, 2, 6, 1, 3, 5, 7 }, 7);
assert(bst.root        != NULL && bst.root->value        == 4);
assert(bst.root->left  != NULL && bst.root->left->value  == 2);
assert(bst.root->right != NULL && bst.root->right->value == 6);
empty_bst(&bst);

// Demonstrate tree_sort_array(…)
int array1[] = { 5, 4, 2, 1, 7, 6, 3 };
size_t size1 = sizeof(array1) / sizeof(*array1);  // # of elements
_print_array(array1, size1, "Before tree_sort_array(array1)");
tree_sort_array(array1, size1);
_print_array(array1, size1, "After  tree_sort_array(array1)");

// Demonstrate quick_sort_array(…)
int array2[] = { 5, 4, 2, 1, 7, 6, 3 };
size_t size2 = sizeof(array2) / sizeof(*array2);  // # of elements
_print_array(array2, size2, "Before quick_sort_array(array2)");
quick_sort_array(array2, size2);
_print_array(array2, size2, "After  quick_sort_array(array2)");

return EXIT_SUCCESS;
}
/* vim: set tabstop=4 shiftwidth=4 fileencoding=utf-8 noexpandtab: */
```

### Output

```Before tree_sort_array(array1)
5 4 2 1 7 6 3

After  tree_sort_array(array1)
1 2 3 4 5 6 7

Before quick_sort_array(array2)
5 4 2 1 7 6 3

After  quick_sort_array(array2)
1 2 3 4 5 6 7```

## Requirements

1. Your submission must contain each of the following files, as specified:
2. file contents
sorts.h type definitions
BST
struct type with 2 fields: `root` (BSTNode*) and `size` (int).
• Whenever `size`==0, `root` must be NULL.
BSTNode
struct type with 3 fields: `value` (int), `left`, and `right` (BSTNode*)
function declarations one for each required function in your sorts.c
• Do not include helpers (if any) here.
sorts.c function definitions
`tree sort array(int✶ array, size t size)`
return type: void
Sort `array` by creating a BST and then traversing it.
• Steps: ① call `create_bst(…)`, ② use in-order traversal to store sorted values in `array` (same memory), ③ call `empty_bst(…)`.
• Store the result in the same array that was passed in.
• This may not result in any heap allocation (i.e., calls to `malloc(…)`), except for the BST nodes allocated as a result of calling `create_bst(…)`; those must be freed before this function returns.
`quick sort array(int✶ array, size t size)`
return type: void
Sort `array` using the `qsort(…)` standard library function.
• This should simply call the `qsort(…)` library function.
• The `qsort(…)` function requires the use of function addresses (function pointers).
• This may not result in any heap allocation (i.e., calls to `malloc(…)`) by your code.
• Yes, this is easy, but make sure you understand how it works!
`create bst(const int✶ array, int size)`
return type: BST
Create a new `BST`.
• `size` is the number of elements in `array`.
• When size==0 array must be NULL and vice versa.
• If size==0 then return a BST with the root set to NULL.
• `malloc(…)` may be called from a total of one place in this function and any it depends on.
`empty bst(BST✶ bst)`
return type: void
Free all the nodes in the BST.
• Set `root` to NULL, and `size` to 0.
• `free(…)` may be called from a total of one place in this function and any it depends on.
test_sorts.c function definitions
`main(int argc, char✶ argv[])`
return type: int
• This must cause every line of code in your sorts.c to be executed.
• Every public function in sorts.c must be called directly from `main(…)` and/or from a helper within test_sorts.c.
expected.txt functions Expected output from running your test_sorts.c
3. Use the `typedef` syntax to declare all struct types.
4. Only the following externally defined functions and constants are allowed in your .c files. (You may put the corresponding #include <…> statements in the .c file or in your sorts.h, at your option.)
stdbool.h `bool`, `true`, `false` `sorts.c`, `sorts.h`, `test_sorts.c`
assert.h `assert` `sorts.c`, `test_sorts.c`
stdio.h `printf`, `fprintf`, `stdout`, `FILE` `test_sorts.c`
stdlib.h `malloc`, `free`, `NULL`, `EXIT_SUCCESS`, `EXIT_FAILURE` `sorts.c`, `test_sorts.c`, `sorts.h`
Feel free to suggest additional header files or functions that you would like to use.
5. Submissions must meet the code quality standards and the policies on homework and academic integrity.

## Submit

To submit HW10 from within your hw10 directory, type `264submit HW10 sorts.h sorts.c test_sorts.c expected.txt miniunit.h clog.h Makefile`

## Pre-tester ●

The pre-tester for HW10 has been released and is ready to use.

## Q&A

1. Where's the starter code? How am I supposed to start?
Learning to program in C entails learning to set up your files and code your project to meet a specification—without being given step-by-step instructions. That said, here is a general process you can use for doing that.
How to do any coding homework in ECE 264
1. First, identify the files you are responsible for producing. In this case, there are four files: sorts.c, sorts.h, test_sorts.c, and expected.txt. Create an (almost) empty file for each.
2. In the .c and .h files, add a Vim modeline. (Tip: In Vim on ecegrid, type `newc` and press Tab to get a skeleton file, including the modeline. Remove any `#include` statements or anything else that isn't needed or allowed.)
3. In the .h file (sorts.h), add an include guard.
4. Create your makefile. This is optional, but recommended. You do not need to use miniunit.h or clog.c in order to use make (but you may if you wish).
5. Submit. Your code is nearly empty, but this gives you a backup.
`make submit` (or `264submit sorts.h sorts.c test_sorts.c expected.txt miniunit.h clog.h Makefile` for Luddites).
6. Decide on a general order in which to implement the various parts of the assignment. For HW10, you could do the three parts in any order. If you have no opinion, we lightly suggest doing in this order: ①`tree_sort_array(…)`, ②`quick_sort_array(…)`. But again, it's up to you.
8. Write one very simple test (e.g., sort empty array). At this point, your sorts.c should have no useful code in it.
9. Write just enough code in sorts.c to pass your easy test.
10. Run your test (e.g., `make test` (or `./test_sorts` for Luddites). Hopefully, your simple test passes. This step is to test the mechanics of your testing, and verify that you have the correct function signatures and such.
11. Add a slightly harder test (e.g., sort array of size one).
13. Run your tests. Make any fixes so that both of your tests do pass.
14. Gradually add tests, extend implementation, run tests, and fix, until one section of your project is complete (e.g., until `create_bst(…)` is working).
15. Follow the above steps to complete the rest of HW10.
16. Re-read the specification—especially the Requirements table—and make sure you have done everything, and your types/fields/functions all match the specification.
17. Check for gaps in your tests. Make sure you get 100% line coverage from `make coverage`. This is no guarantee of perfection, but if you don't have 100% coverage, you need to fix that. Make sure your tests cause every part of your implementation code to be executed.
18. Think through your tests carefully. Make sure you have covered all:
• “edge cases” – extreme values
• “corner cases” – values that cause your code to behave differently
• “special cases” – exceptions to normal functionality described in the specification
• "easy cases" – easy for you to understand
(Note: These are not standard terms.)
2. Can I add helper functions to sorts.c?
Yes. Make sure the names begin with "_".
3. Is there a warm-up?
No.
4. Is it a violation of the spec if `qsort(…)` calls `malloc(…)`?
No. The only requirement is that your code not call `malloc(…)` as a result of calling `quick_sort_array(…)`.
5. Should I use recursion for the BST operations (`create_bst(…)`, `tree_sort_array(…)`, and `empty_bst(…)`)?
Long answer: All of these things can be accomplished without recursion, using only `while` loops. However, those methods are messier.
The methods demonstrated in class (see snippets) use recursion, and that is what we recommend.
6. How do I create a BST? … delete a BST?
To create a BST, start with an empty BST (`root = NULL`) and then insert each element you wish to add.
To delete a BST, delete the left and right subtree (recursively). Then, free the root.
7. What is “in-order traversal”?
With in-order traversal means you “visit” (i.e., do something with) the left subtree, then the root, and finally the right subtree. In that example, “visit” meant printing the value of a node. For a BST, this results in printing the values in order.
You will learn a bit more about tree traversals later, but for HW10, this is all you need to know.
Example:
In the `print_bst(Node* root)` function in the snippet:
1. Print the left subtree by calling `print_bst(root -> left)`recursively.
2. Print the root by calling `printf("%d\n", root -> value)`.
3. Print the right subtree by calling `print_bst(root -> right)`recursively.
If the tree has zero nodes (i.e., empty), we do nothing.
If the tree has one node (i.e., root has no children):
1. `print_bst(root -> left)` has no effect.
2. `printf("%d ", root -> value)` prints 4 .
3. `print_bst(root -> right)` has no effect.
If the tree has three nodes (i.e., root has children but no grandchildren):
1. `print_bst(root -> left)` prints 2 .
2. `printf("%d ", root -> value)` prints 4 .
3. `print_bst(root -> right)` prints 6 .
Altogether, it prints 2 4 6 .
If the tree has seven nodes (i.e., root has children but no grandchildren):
1. `print_bst(root -> left)` prints 1 2 3 .
2. `printf("%d ", root -> value)` prints 4 .
3. `print_bst(root -> right)` prints 5 6 7 .
Altogether, it prints 1 2 3 4 5 6 7 .
For `tree_sort_array(…)`, you are following the same process, except instead of printing a value with `printf(…)`, you store it in the array.
